Marina Power Company -- Power Centers

The PCII power center is designed to provide power and communication services for two yachts, each of which may require up to 100 or 200 amps of electrical service. The center is self supporting and the mounting bolts are concealed within the unit.

Services available for each yacht include light, power, power metering, water, TV, telephone and security. All components are marine grade. The power service in the PCII 12 (12" square) may consist of up to 6 receptacles and circuit breakers of 50 amps or less. The PCII 16 (16" square) may contain up to four 100 amp receptacles or one 200 amp receptacle and circuit breakers. All services are protected by weather proof lift covers. The fluorescent lighting provides pleasant, low brightness illumination which is more than adequate for most marina applications.

The construction of the PCII is marine durable in every way. The housing is of 1/8" No. 5052 marine grade aluminum and all other parts are of No. 316 stainless steel.

The following features are unique to Marina Power Company
power centers and are available in no other unit.

All metal construction -- Marine grade aluminum and stainless steel.
No polycarbonate to deteriorate in the sunlight.
Self-contained dock light that makes other lighting unnecessary.
Matching light bollards available where additional lighting is desired.
Water Connections are hidden.
All power and communications connections are under weather proof covers.
All individual parts are easily replaceable in the event of damage.
Up to 400 AMP capacity with four 100 AMP receptacles.
Electric power meters and water meters available.
For use in RV parks and for electric golf carts.

The PCII is listed by Applied Research Laboratories,
the PCII 12 up to 300 amps and the PCII 16 up to 400 amps.
